On the final day of a workbench class, the students either assemble all their benches or pack up the parts in their cars to assemble things at home.
Assembly is easy. I usually do it by myself, but I never decline offers of help. Plus, it’s the best part of the entire job because it is usually followed immediately by beer.
During this class at Dictum GmbH in Germany, I built a bench along with the students to leave with the school. Because I was also teaching, troubleshooting and helping out, I was running way behind everyone when the day began on Sunday morning.
Before lunch I cut all the mortises in the top (thanks to the Mafell chain mortiser), fit all my legs and stretchers and planed off all the tool marks on the pine. After lunch I drilled all the holes for the drawbores and prepared my beech pins and wedges.
The rest was easy. Here are some things to consider after you watch the little movie.
1. You don’t have to use glue in the mortises and tenons. Drawbores and wedges do the work just fine. Glue is cheap, so why not use it? I prefer hide glue but we had used it all up the day before.
2. All the drawbore pins are lubricated with wax. I usually use paraffin, but we used all that up. So I used beeswax.
3. The base joints are fit a tad loose. The joints to the top are fit tight. This makes assembly easier.
4. Use a big sledge to drive the drawbore pins. And big-diameter pins. These are about 3/4”.
5. Once you start assembly, do not stop. But do not rush. I made a mistake in the film because I failed to double-check my cabinetmaker’s triangle, but it worked out OK in the end.
6. Drive the wedges into the top until they stop moving. If they crack, stop hitting them.
7. Throwing axes after assembly is not essential, but it is highly recommended. Follow that with beer.
— Christopher Schwarz
Other videos in this series on building a bench in Germany:
1. French Bench. German School. American Teacher. Day 1.
2. Mafell Chain Mortiser. Dang.
3. More Mafell Madness: Day 3 of the Workbench Class
4. My Assembly Tricks for Old World Workbenches
Here are some supplies and tools we find essential in our everyday work around the shop. We may receive a commission from sales referred by our links; however, we have carefully selected these products for their usefulness and quality.
Hi Chris,
I’m absolutely new in woodworking and started this hobby building my roubo which will be assembled within the next days. You recommend hide glue instead of titebond. Is it the same assembling procedure or do I have to observe something special because the short open time etc.?
Thanks
Michael
Germany
I have to have a large ( 28″DIA) Ash tree cut down. If this wood is a good choice for a workbench how should I have it cut?
Six inch thick quartersawn, 2″ thick quartersawn ( easier drying), 6×6 timbers ?
Thanks
Riverbend
Couldn’t find the cut list or drawings.
I just want to know where the Birmingham jail is!
Chris,
As I watch you evolve your workbench design I am wondering if you have posted a sketch up model of the new design or are planning an addendum to one of your workbench books? Also, did you cut the mortises on the bench top a little large to accommodate the wedge afterwards?
Thanks
Josh
One of the German traditions of successful project completion is to “pour beer over it”. If you pour it on the bench top, you have missed the message.
Chuck Walker
How much was your offset when using a 3/4″ drawbore pin?
Just to clarify, the axe throwing is BEFORE the beer drinking, right?
What was the beer of choice?
Jonathan
==============================
Who is singing Birmingham Jail in this video? Musical credits would be an awesome addition to future videos since most of them I want to hunt down and purchase.
